Key Features:

1. Advanced Positioning Capabilities:

• Displays precise latitude and longitude information.

2. Trajectory Tracking:

• Tracks flight paths of UAVs and movement trajectories of remote controllers (pilots) in distinct colors.

3. Multi-Target Detection and Positioning:

• Detects and locates over 10 types of UAVs.
• Identifies and recognizes over 35 drones at the same time.
• Detects 10+ types of UAVs and 10+ types of remote controls simultaneously.

4. Intelligent Intrusion Detection:

• Automatically merges repeated detections of the same drone within a defined timeframe into a single record.
• Uses electronic fingerprint IDs to unify intrusion data across multiple detections.

5. Detection, Direction Finding, and Positioning:

• Detects and recognizes signals from DJI, Wi-Fi drone, DIY drone (analog image transmission), etc.
• Displays key information of drones
• Displays key information of remote control (pilot)

Technical Specifications:

1. Dimensions and Weight:

• Size: Length: 410±2mm, Width: 330±2mm, Height: 190±2mm
• Weight: ≤12.8kg

2. Frequency Range:

• 25MHz~6000MHz

3. Main Frequency:

• 400MHz, 800MHz, 900MHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz

4. Detection Performance:

• Range: 5KM
